Intel® NUC 9 Pro NUC9VXQNX



  • Intel® Xeon® E-2286M processor
  • 2x Thunderbolt 3, HDMI 2.0a
  • 2x M.2 SSD
  • 2x DDR4 DIMMs
  • Discrete graphics card support

Features

  • Chassis Dimensions:
    - 9.37" x 8.5" x 3.77"
    - 238mm x 216mm x 96mm
  • Intel® Xeon® E-2286M Processor (16M Cache, 2.40 GHz) Specs
  • 2x DDR4 SO-DIMM Sockets (up to 64 GB)
  • Graphics:
    - Intel® UHD Graphics P630
    - 2x Thunderbolt 3, HDMI 2.0a
    - Supports 3x 4K Displays
    - Discrete Graphics Card Support
  • Expansion Options:
    - 2x M.2 PCIe 3.0 x4 Slots (PCH)
    - 1x M.2 PCIe 3.0 x4 Slot (CPU)
    - Double-wide PCIe 3.0 x16 (CPU) Slot shared with PCIe x4 (CPU) Slot, 8" Max Card Length
  • Connectivity:
    - HDMI 2.0a Port
    - 2x Thunderbolt™ 3 Ports
    - 6x USB 3.1 Gen2 Type-A Ports
    - Intel® Gigabit Ethernet LAN i219-LM and i210-AT
    - Intel® Wi-Fi 6 AX200
    - Bluetooth® v5
    - SDXC with UHS-II Support
  • Audio:
    - Up to 7.1 Multichannel Digital Audio via HDMI or Thunderbolt 3
    - L+R+mic (F); L+R+TOSLINK (R)

Download Product Brief


Images


$2,124.25


  Qty.Intel NUC 9 Pro - NUC9VXQNX (Xeon E-2286M), Cost As Configured $2,124.25
Base Platform 1
Socket 1 1
Socket 2 1
M.2 Drive 1 1
M.2 Drive 2 1
Enhanced Video 1
Operating System SW 1
   Intel NUC 9 Pro - NUC9VXQNX (Xeon E-2286M), Cost As Configured $2,124.25
