Colfax CX44512s-JBOD




  • 45x 3.5" HDD Bays
  • 4x Mini-SAS HD Ports for Internal / External Cascading
  • High Efficiency Redundant Power

Features

  • 45x 3.5" Top Loading SAS/SATA 12Gb/s Hot-Swap HDD/SSD Bays
  • Tool-less HDD tray with HDD LED indicator
  • Single Expander Backplane Boards support SAS3 with 12Gb/s throughput
  • 4x Mini-SAS HD ports for Internal / External Cascading Expander Combination
  • 1600W Redundant Power Supplies; 80PLUS Platinum Certified
  • 5x Hot-Swap Cooling Fans
  • 1x IPMI Port for Remote System Power on/off and System Monitoring




Technical Specifications

Chassis Form Factor • 4U Rackmount
• Dimensions: Height 7" (178mm), Width 17.2" (437mm), Depth 26" (660 mm)
Storage • 45x 3.5" hot-swap SAS/SATA drive bay with SES3
Backplane • 45-port 4U SC946L Top-load SAS3 12Gbps expander backplane, supports up to 45x 3.5-inch SAS3/SATA3 HDDs/SSDs
System Cooling • 5 x 80mm rear hot-swap exhaust PWM fan(s)
Power Supply • 1600W redundant power supply with PMBus & I2C
Total Output Power and Input
• 1000W with Input 100 - 127Vac
• 1600W with Input 200 - 240Vac
AC Input Frequency
• 50-60Hz
+12V
• Max: 82A / Min: 0.1A (100-127Vac)
• Max: 132A / Min: 0.1A (200-240Vac)
12V sb
• Max: 2A / Min: 0.2A
Power Distributor
• PDB-PT946S-L824
• O/P: 12V/200
• +5V Max: 25
• +3.3V Max: 25
Certification
• 80 PLUS Platinum Level Certified
Front Panel Buttons
• Power On/Off button
• UID button
LEDs
• Network Activity LED
• Power Status LED
• Power Fail LED
• System Information LED

Images


$3,700.00


  Qty.Colfax CX44512s 4U 45 Bay SAS 12Gb/s JBOD, Cost As Configured $3,700.00
Base Platform 1
Disk Drive 1    1

Set next    items (  ) like this
Disk Drive 2    1
Disk Drive 3    1
Disk Drive 4    1
Disk Drive 5    1
Disk Drive 6    1
Disk Drive 7    1
Disk Drive 8    1
Disk Drive 9    1
Disk Drive 10    1
Disk Drive 11    1
Disk Drive 12    1
Disk Drive 13    1
Disk Drive 14    1
Disk Drive 15    1
Disk Drive 16    1
Disk Drive 17    1
Disk Drive 18    1
Disk Drive 19    1
Disk Drive 20    1
Disk Drive 21    1
Disk Drive 22    1
Disk Drive 23    1
Disk Drive 24    1
Disk Drive 25    1
Disk Drive 26    1
Disk Drive 27    1
Disk Drive 28    1
Disk Drive 29    1
Disk Drive 30    1
Disk Drive 31    1
Disk Drive 32    1
Disk Drive 33    1
Disk Drive 34    1
Disk Drive 35    1
Disk Drive 36    1
Disk Drive 37    1
Disk Drive 38    1
Disk Drive 39    1
Disk Drive 40    1
Disk Drive 41    1
Disk Drive 42    1
Disk Drive 43    1
Disk Drive 44    1
Disk Drive 45    1
Ext RAID Controller 1
Ext SAS Cable 1    1

Set next    items (  ) like this
Ext SAS Cable 2    1
Ext SAS Cable 3    1
Ext SAS Cable 4    1
   Colfax CX44512s 4U 45 Bay SAS 12Gb/s JBOD, Cost As Configured $3,700.00
