Colfax CX2220LPs-S48-X7 2U Rackmount Server



  • 2x Intel® Xeon® Scalable Processors
  • 48x 2.5" Hot-Swap SAS3/SATA3 Drive Bays
  • 2x 2.5" Hot-Swap Rear Drive Bays
  • Broadcom 3108 SAS3 Controller

Features

  • 2x Intel® Xeon® Scalable Processors
  • Intel C624 Chipset
  • 24x DIMMS, Supports DDR4 ECC RDIMMM/LRDIMM
  • Expansion Slots
    - 2x PCI-E 3.0 x16 Slots
    - 1x PCI-E 3.0 x8 Slot
    - 1x SIOM Slot for Networking Card
  • 48x 2.5" Hot-Swap SAS3/SATA3 Drive Bays + 2x 2.5" Hot-Swap SATA3 Rear Drive Bays
  • Integrated Broadcom 3108 SAS3 (12Gbps) Controller; RAID 0, 1, 5, 6, 10, 50, 60
  • 1600W Redundant Power Supply, 80PLUS Titanium
  • Integrated IPMI 2.0 with KVM and Dedicated LAN




Intel, the Intel logo, Xeon, and Xeon Inside are trademarks or registered trademarks of Intel Corporation in the U.S. and other countries.

Technical Specifications

CPU • Dual Socket P (LGA 3647)
• Supports Intel® Xeon® Scalable processor (70-205W TDP)
Memory • 24x DDR4 DIMM slots
• Up to 3TB ECC 3DS LRDIMM, 768GB ECC RDIMM, DDR4 up to 2666MHz
• 2666/2400/2133MHz ECC DDR4 SDRAM
Chipset • Intel® C621
I/O Expansion • 2x PCI-E 3.0 x16 slots
• 1x PCI-E 3.0 x8 slot
• 1x SIOM slot for networking card
Onboard Devices SATA
• SATA3 (6Gbps); RAID 0, 1, 5, 10, 50 support
SAS
• SAS3 (12Gbps) via Broadcom 3108; HW RAID; RAID 0, 1, 5, 6, 10, 50, 60
IPMI
• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
VGA
• ASPEED AST2500 BMC
Input / Output SATA
• 8 SATA3 (6Gbps) ports
LAN
• 1x RJ45 Dedicated IPMI LAN port
USB
• 2x USB 3.0 ports (rear)
• 1x Type A
VGA
• 1x VGA D-Sub connector port
Serial Port / Header
• 1 Fast UART 16550 port / 1 Header
Chassis Form Factor • 2U Rackmount
• Dimension: 17.2"W (437mm) x 3.5" (89mm) x 30" (684mm)
Power Supply • 1600W 1U Redundant Power Supplies with PMBus
Total Output Power
• 1600W/1000W
Input
• 100-127Vac / 13 - 9A / 50-60Hz
• 200-240Vac / 10 - 8A / 50-60Hz
+12V
• Max: 83.3A / Min: 0A (100-127Vac)
• Max: 133A / Min: 0A (200-240Vac)
12V sb
• Max: 2.1A / Min: 0A
Certification
• 80PLUS Titanium Certified
Storage • 48x hot-swap 2.5" SAS3/SATA3 drive bays (24x drives in front of the chassis and 24x drives in pop-up riser drive bays on top of the chassis
• 2x hot-swap 2.5" SATA drive bays (rear)
Backplane • SAS3 12Gb/s direct attached storage backplane, w/ 24x SAS3 2.5" drive slots
System Cooling • 5x 8cm high-performance PWM fans
Front Panel Buttons
• Power button
• System Reset button
LEDs
• Power LED
• Hard drive activity LED
• Network activity LEDs
• System information LED
• Power fail LED
BIOS • AMI UEFI
